Tyco Kantech
Kantech, a division of Tyco Security Products, specializes in the design, marketing, and support of integrated access control technologies that are readily deployable. Access control serves as the primary means of safeguarding your property. Secure Lattice FZC offers a comprehensive selection of Tyco software house access control systems, solutions, and products. Access control represents the foremost and most influential element in ensuring the safety and security of your facility.
Kantech’s solutions offer a compact, entry-level solution suitable for small, medium, and large businesses. Kantech provides a complete suite of access control products that are dependable, effortless to install, and highly scalable. Our security management software for single workstations, such as KT-1 or KT-400, utilizes modern technology to identify individuals based on unique physical traits. Numerous Tyco access control solutions incorporate remote monitoring, simplifying security management. We provide comprehensive Tyco Kantech access control products, including integrated software, to ensure that your security system is well-equipped and capable of much more.
Tyco Kantech Products
EntraPass Special Edition Security Software
EntraPass Special Edition is security management software for a single workstation with the ability to control a single door with the KT-1, up to 128 doors with KT-100/KT-300 and up to 256 doors with KT-400 door controllers. The software is comprehensive and menu-driven. It is easy to learn and operate.
- Integrates with telephone entry systems
- Embedded Sybase SQL database engine
- Built-in e-mail reporting capability
- Integrates with Exacq video management systems, American Dynamics (DVRs/NVRs, HDVR, ADTVR and Intellex) and DSC PowerSeries, PowerSeries Neo, PowerSeries Pro and MAXSYS intrusion alarm panels
- Double and triple swipe card at reader.
EntraPass Corporate Edition Security Software
EntraPass Corporate Edition is a multiple workstation software platform that offers the ultimate balance between power and affordability in a network environment.
- Gain access to doors with a one-time unlock command using the EntraPass go Pass mobile app
- Automatically move legacy controllers to KT-1 or KT-400 door controllers eliminating the need to reprogram
- Supports up to 20 workstations and controls hundreds of thousands of doors
- Import/synchronize EntraPass operators and users (cardholders) with Microsoft Active Directory for centralized management*
- Automatically log into EntraPass with Windows credentials using Single Sign On in Microsoft Active Directory*
- Embedded Sybase SQL database engine
- Supports up to 50 concurrent logins of EntraPass web and/or EntraPass go
- Integrates with Exacq video management systems, American Dynamics DVRs/NVRs (VideoEdge, HDVR, ADTVR and Intellex), INTEVO integrated security platform and DSC PowerSeries, PowerSeries Neo, PowerSeries Pro and MAXSYS intrusion alarm panels
- Double and triple swipe card at reader (with KT-400 controller) to activate such features as: activate relay, arm alarm system and lock/unlock doors
- Integrates with ASSA ABLOY Aperio wireless locks for integrated and management lock solution
EntraPass Global Edition Security Software
EntraPass Global Edition is a powerful, network-ready enterprise level security management software that accommodates widely-dispersed applications with an unlimited number of users, controls thousands of doors and allows you to simultaneously access the system from up to 128 workstations connected to the network.
- Gain access to doors with a one-time unlock command using the EntraPass go Pass mobile app
- Automatically move legacy controllers to KT-1 or KT-400 door controllers eliminating the need to reprogram
- Supports up to 128 workstations and controls hundreds of thousands of doors
- Integrates with EntraPass web (remote user platform) to manage access control, IP video, telephone entry and/or intrusion security assets
- Supports up to 250 concurrent logins of EntraPass web and/or EntraPass go
- Integrates with Exacq video management systems, American Dynamics DVRs/NVRs (VideoEdge, HDVR, ADTVR and Intellex), INTEVO integrated security platform and DSC PowerSeries, PowerSeries Neo, PowerSeries Pro and MAXSYS intrusion alarm panels
- Double and triple swipe card at reader (with KT-400 controller) to activate such features as: activate relay, arm alarm system and lock/unlock doors
KT-2 Two Door Controller
KT-2 Ethernet-ready two-door controller supports two readers and can be configured in two user friendly operational modes. The KT-2 Standalone Mode offers basic two-door security using a simple web browser without the need to connect to a host system.
- Two Door IP Controller (Entry)- Supports 2 readers
- Wi-Fi Connectivity reduces installation costs
- Single touch-sensitive button for fast Plug & Play installation
- Automatic controller enrollment (EntraPass Security Software)
- In Standalone, configure and manage two doors using a simple embedded web browser – no software to purchase and install
- Intuitive configuration wizard for quick set up
- Flexible power input – Power over Ethernet (PoE), POE+ or 12 VDC
- Compatible with existing Kantech controllers including KT-1, KT-300 and KT-400
KT-1 One Door Controller
KT-1 is an Ethernet-ready single door controller, supporting two readers – IN/OUT and configurable in two modes providing advanced access control features when used with EntraPass Security Software (v6.02 and higher) or basic door security without the need to connect to a host system when in Standalone Mode.
- One Door IP Controller - Supports 2 readers (entry and exit)
- Single touch-sensitive button for fast & automatic controller enrollment (EntraPass Security Software)
- Configure and manage a single door using a simple embedded web browser – no software to purchase and install
- Power over Ethernet (PoE) – Flexible power input
- LED status indicators for maintenance trouble shooting
- Compatible with existing Kantech controllers including KT-300 and KT-400
KT-400 Ethernet-Ready Four-Door Controller
KT-400 is an Ethernet-ready four-door controller that provides 128-bit AES encrypted communication with the EntraPass Security Software and is a highly secure solution for any security-conscious business. KT-400 can easily be integrated into an existing EntraPass system with other Kantech controllers (KT-1 and KT-300)
- Configure and manage four doors using a simple embedded web browser – no software to purchase and install (Standalone Mode, KT-400rev1)
- Intuitive configuration wizard for quick set up (Standalone Mode, KT-400rev1)
- Onboard Ethernet 128-bit AES-encrypted communication with the EntraPass system ensures a high degree of network security
- 100,000 cards capacity and provides up to 20,000 concurrent events in stand-alone mode
- 256 outputs (four onboard) provide scalability
- Verify and configure IP settings with a built-in web configuration page
- Supervised door lock outputs with internal or external power supply
- LEDs provide important controller status and diagnostic information
- Additional battery supervision and monitoring help ensure controller functionality
KT-300 Door Controller
The KT-300 door controller supports up to two readers, which can be installed either on a single door (to monitor both entry and exit) or on two separate doors. It provides connections for all peripheral devices necessary for a complete access control system and can be linked with other door controllers to provide control over millions of doors.
- Controls two doors and easily links to a network
- Update the firmware directly from system workstation
- Fast, up to 115,200 baud
- Ready to go, no DIP switches or jumpers to set
- 5V and 12V reader power
- Interfaces with an external alarm system
- Automatic trouble reporting
- All power outputs are individually protected against short circuits and surges by a self-resetting PTC
- Choice of two memory capacities, 128K or 512K
KT-NCC Network Communication Controller
Kantech KT-NCC is a powerful way to expand an EntraPass Global Edition System. Instead of relying on a PC for communication between the controllers and server, the dependable KT-NCC is in control.
- Powerful panel architecture removes a layer of PCs to improve reliability and save money
- Onboard TCP/IP eliminates the need for an external network communication device
- Supports any combination of up to 128 controllers (KT-100, KT-300, or KT-400)
- Embedded redundancy ensures critical data is always protected
- Seven LED modes provide quick assessment of system status
- Flashable firmware enables fast, convenient updates
- Battery backup provides alternative for Universal Power Supply (UPS)
- Global functionality such as anti-passback, guard tours, and alarm systems management is easier than
Readers, Keypads & Cards
Smart Card
- Smart Card readers provide a much higher level of security than standard proximity or magnetic stripe readers. Kantech offers a full suite of smart card readers to fit your unique needs
Proximity Card Readers and Cards
- Our proximity card readers and cards include ioProx, HID and ShadowProx. These readers provide reliable performance and can be installed in various indoor and outdoor environments.
Wireless
- The demand for wireless technology has been on the rise as people endeavor to expand their access control system with additional doors economically.
Multi-Technology Readers
- Kantech Multi-Technology Readers provide a multi-protocol, multi-frequency solution that reads many technologies, including ioProx with Kantech XSF format.
Biometric Recognition
- Biometric readers are used to determine a person’s identity by detecting and matching the person’s physical features, such as fingerprints or hand geometry to a database
Polaris-2 Mag-Stripe Card Readers and Cards
- The POL-2 and POL-2KP magnetic stripe readers are the new generation of the popular Polaris series. Packed with new features, the Polaris-2 series provides the right combination of quality and reliability.
Long Rang Reader and short Rang Reader
- uPASS Target reader, High-end UHF reader for long-range identification up to 10 meters and 5meters from Nedap
Keypads
- keypads can be used to restrict entry to sensitive areas by requiring individuals to enter a code.
Accessories
Input / Output Modules & Alarm Panel Integration Kits
- Kantech input / output modules and accessories provide a flexible, easy to use, and cost-effective means to expand the functionality of KT-1 and KT-400 door controllers.
Badge Printing Solutions
- Our badge printers produce colorful, durable photo cards. These printers are simple to use and virtually maintenance free, includes HID Frago.
Locks & Push-button (PB) Exit Detector
- ioProx readers easily meet the demands of any application. They are a secure and easy-to-install solution to manage and control access all the while ensuring the safety of people and property
